DD422i: Sandvik underground power for mining operations

Sandvik DD422i Dual Controls allows true multipurpose usage of the drill, improving fleet optimization, versatility and performance. It can be used across multiple applications: face drilling, bolt hole drilling and bolting.

Features

Drilling control panels

The design of the electronic controls ensure easy operations even in the toughest work environments. The 4 joysticks and separate control panels per boom help the operator within multi-task operations, i.e. boring, bolting, meshing and scaling.

Drilling control panels

The design of the electronic controls ensure easy operations even in the toughest work environments. The 4 joysticks and separate control panels per boom help the operator within multi-task operations, i.e. boring, bolting, meshing and scaling.

The design of the electronic controls ensure easy operations even in the toughest work environments. The 4 joysticks and separate control panels per boom help the operator within multi-task operations, i.e. boring, bolting, meshing and scaling.
Pumpable resin system

This optional system is fast and highly reliable, it supports Rebar, Self drilling (SDB) and Hollow bar bolt types.The process is monitored and automatically controlled from inside the cabin. Only the required amount of resin to fill the drilled hole is used.

Pumpable resin system

This optional system is fast and highly reliable, it supports Rebar, Self drilling (SDB) and Hollow bar bolt types.The process is monitored and automatically controlled from inside the cabin. Only the required amount of resin to fill the drilled hole is used.

This optional system is fast and highly reliable, it supports Rebar, Self drilling (SDB) and Hollow bar bolt types.The process is monitored and automatically controlled from inside the cabin. Only the required amount of resin to fill the drilled hole is used.
Wireless angle control system

The system provides accurate drilling angle information for both drilling and bolting
purposes, displaying real-time feed angle data directly on the operator’s screen
inside the cabin. It operates on battery power and connects via Bluetooth® to the drill’s user interface for seamless integration and ease of use.

Wireless angle control system

The system provides accurate drilling angle information for both drilling and bolting
purposes, displaying real-time feed angle data directly on the operator’s screen
inside the cabin. It operates on battery power and connects via Bluetooth® to the drill’s user interface for seamless integration and ease of use.

The system provides accurate drilling angle information for both drilling and bolting
purposes, displaying real-time feed angle data directly on the operator’s screen
inside the cabin. It operates on battery power and connects via Bluetooth® to the drill’s user interface for seamless integration and ease of use.

Learn more about DD422i features

Drill bit changer

Drill a full round, without leaving the cab to manually change the bit, with Sandvik's patented drill bit changer available through automation upgrade package. Reduce dependency on bit life while drilling and improve operator safety by limiting the time they spend in front of the drill.

Resin capsules injection system

This option uses resin capsules as bolting mechanism improving safety and enabling faster cycle time in the rock support process. Capsules are injected into the end of the hole through a chamber located on the right entrance of the cabin or on the front right mudguard.

Digital Driller™

Through simulation, operators develop skills fully from basic boom movements and manual drilling operations using various training scenarios.

Product specifications

Download DD422i dual drilling controls specification sheet (PDF)

Download DD422i-DD422iE dual controls pumpable resin specification sheet (PDF)

DD422i and DD422iE CO2e emissions - average equipment

My Sandvik

DD422i operating manual and spare parts

Operating manuals and spare parts can be found on the My Sandvik customer portal.

Go to My Sandvik

Coverage: 60 m²
Hole length: 3.44 - 5.88 m
Tramming type and distance: Hydrostatic transmission - Diesel engine - QSB4.5 (127 kW Tier 3 Stage IIIA )
Hole diameter: 43 - 64 mm
Number of booms: 2 x SB60
Drift size (H x W): 4.5 x 4.5 m
Feed length: Fixed TF500 12 to 20 ft. or telescopic TFX 6-12 ft. to 10-16 ft.
Rock drill: RD525 25kW
Voltage: 380 - 1,000 V (multi voltage)
Controls type: SICA (Sandvik Intelligent Control System Architecture) with THC561 look control panel
Weight: 26,000 kg (depending on options)

Coverage: 60 m²
Hole length: 3.44 - 5.88 m
Tramming type and distance: Hydrostatic transmission - Diesel engine - QSB4.5 (127 kW Tier 3 Stage IIIA )
Hole diameter: 43 - 64 mm
Number of booms: 2 x SB60
Drift size (H x W): 4.5 x 4.5 m
Feed length: Fixed TF500 12 to 20 ft. or telescopic TFX 6-12 ft. to 10-16 ft.
Rock drill: RD525 25kW
Voltage: 380 - 1,000 V (multi voltage)
Controls type: SICA (Sandvik Intelligent Control System Architecture) with THC561 look control panel
Weight: 26,000 kg (depending on options)
