Mineral Bolt

The Mineral Bolt is a two-component, organic and mineral resin with high strength. Mineral Bolt is engineered for the installation of rock bolts. The resin is designed to firmly fix mechanical bolts or anchors in the borehole, stabilize grout for heavily cracked rock mass, seal against gas penetration, and stop water inflows.

Features

Adjustable

The Mineral Bolt has an adjustable setting time and can be used in a broad range of ambient temperatures.

Adjustable

The Mineral Bolt has an adjustable setting time and can be used in a broad range of ambient temperatures.

The Mineral Bolt has an adjustable setting time and can be used in a broad range of ambient temperatures.
Automated

The resin is suitable for mechanized automatic application. It also offers automated rock bolting, which prevents mixing errors.

Automated

The resin is suitable for mechanized automatic application. It also offers automated rock bolting, which prevents mixing errors.

The resin is suitable for mechanized automatic application. It also offers automated rock bolting, which prevents mixing errors.
Fast curing

Rapid response and fast curing mean optimized tunneling performance.

Fast curing

Rapid response and fast curing mean optimized tunneling performance.

Rapid response and fast curing mean optimized tunneling performance.

Product specifications

Mineral Bolt flyer - EMEA (PDF)

Appearance: Component A: pale yellow liquid / Component B: dark brown liquid
Reaction time: 20 to 600 seconds
Density at 20˚C: Component A: 1.40±0.06 g/cm³ / Component B: 1.20±0.06 g/cm³
Viscosity at 25˚C: Component A: 300±90 mPa*s / Component B: 220±90 mPa*s ^*
Max. reaction temperature: at 25˚C < 140˚C / at 10˚C < 125˚C

Product specification may vary by region. Please download the data sheet specific to your region.
For questions, contact us via the form on our website or the contact details provided in the data sheet. Always confirm key specifications with your local representative.

^* *results obtained under laboratory conditions

Safe, efficient bolting – Seamlessly integrated with Sandvik underground drill rigs

New pumpable resin package for Dual Controls

The new pumpable resin package for Dual Controls enhances bolt installation, giving operators full control in challenging ground. It’s fully compatible with Versabolt™ for dynamic conditions, as well as DSI Hollow Bar System / Self-Drilling Bolts, and Resin Roof Bolts.

New pumpable resin system for DS412i and DS412iE bolters

Safety, quality and productivity were the pillars in the development of this new product offering, ensuring optimal performance. Featuring Mineral Bolt pumpable resin, the set-up supports self-drilling bolts (SDB) and hollow bar bolts (HBB), as available from the DSI Hollow Bar System. The option is also available for Sandvik DS512i machines, as a custom order.

Post-grouting installation for high productivity

The DSI Hollow Bar System is designed for post-grouting installation to maximize productivity and safety, even in complex geology and are also compatible with new pumpable resin system. Ideal for deep mining, block caving, and rehabilitation projects.

Our range of urea-silicate

Urea-Silicate

Mineral Fill

Appearance: Component A: colourless liquid / Component B: dark brown liquid
Foam factor: at 25˚ C with 40±10
Reaction start time: at 25˚ C in 10 - 20 seconds

Urea-Silicate

Mineral Bond

Appearance: Component A: colourless liquid / Component B: dark brown liquid
Foam factor: at 25˚C with 1.0
Reaction start time: at 25˚ C in 30 - 60 seconds
